SCA-4-10+
SCA-4-10+
| Part Number | SCA-4-10+ |
|---|---|
| Manufacturer | Mini-Circuits |
| Category | RF Power Splitters; 4-Way Resistive Power Splitter/Combiner |
| Description | 4-Way Resistive Power Splitter/Combiner, DC to 1000 MHz, 50Ω, SMD-10 Package |
Product Overview
The SCA-4-10+ is a high-performance 4-way resistive power splitter/combiner designed for wideband RF and low-frequency applications. It operates seamlessly from DC to 1000 MHz with 50Ω impedance matching, low insertion loss, excellent amplitude balance, and consistent phase tracking across the entire bandwidth. Built with high-reliability surface-mount technology, this device delivers stable performance, high isolation between ports, and robust operation in industrial and commercial environments. Its compact SMD form factor enables easy integration into high-density RF circuits, test systems, and communication equipment.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | Mini-Circuits |
| Configuration | 4-Way Resistive Splitter/Combiner |
| Frequency Range | DC to 1000 MHz |
| Impedance | 50Ω |
| Package Type | SMD-10 |
| Operating Temperature | -40°C to +85°C |
Typical Applications
- RF Signal Distribution & Combining
- Test & Measurement Equipment
- ISM Band Communication Systems
- RF Receiver & Transmitter Modules
- Industrial Control & Sensor Interfaces
- Broadband Low-Frequency RF Systems
- High-Density PCB RF Circuits
- Laboratory & R&D Signal Testing
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
