MAX30101EFD
MAX30101EFD
| Part Number | MAX30101EFD |
|---|---|
| Manufacturer | Maxim Integrated (Analog Devices) |
| Category | Optical Sensors; Heart Rate and SpO2 Sensor |
| Description | 18bit Integrated Heart-Rate and SpO2 Sensor Module, I2C Interface,1.7V~2V, Low Power, OLGA-14(3.3×5.6) Package |
Product Overview
The MAX30101EFD is a high-integration, low-power optical sensor designed for heart-rate monitoring and pulse oximetry (SpO2) applications. It integrates red and IR LEDs, photodetectors, optical elements, and low-noise signal processing circuits. The sensor features high sensitivity, low power consumption, and a compact form factor, making it ideal for wearable health devices, fitness trackers, and medical monitoring equipment.
| Key Specifications | |
|---|---|
| Brand | Maxim Integrated (Analog Devices) |
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Package / Case | OLGA-14(3.3×5.6) |
| Mounting Type | Surface Mount (SMD) |
| Surface Marking / Silkscreen | MAX30101EFD |
| Measurement Functions | Heart Rate (HR), SpO2 |
| Interface | I2C Serial Interface |
| Supply Voltage | 1.7V~2V |
| Operating Temperature | -40°C to +85°C |
Typical Applications
- Wearable Fitness Trackers & Smart Watches
- Portable Heart Rate Monitors
- Medical SpO2 & Pulse Oximetry Devices
- Smart Clothing & Health Monitoring Wearables
- Mobile Phone Health Sensors
- IoT Health Care Devices
- Battery-Powered Medical Equipment
- Home Health Monitoring Systems
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Payment Methods: T/T (Bank Transfer), PayPal, Credit Card, Western Union
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
