MB86276PB-GS-ZE1
MB86276PB-GS-ZE1
| Part Number | MB86276PB-GS-ZE1 |
|---|---|
| Manufacturer | Fujitsu / SocioNext |
| Category | Integrated Circuits (ICs) > Linear – Video Processing / Graphics Controllers |
| Description | High-performance 2D/3D graphics controller IC (“Lime”) optimized for embedded automotive and industrial display systems. |
Product Overview
The MB86276PB-GS-ZE1, popularly known as the “Lime” graphics controller, is a highly optimized, single-chip 2D/3D graphics processor designed specifically for high-reliability embedded systems, automotive instrument clusters, and advanced industrial control panels. Developed with an architecture that prioritizes rich display capabilities and stable operation, this IC balances exceptional rendering performance with a low thermal footprint. It integrates dedicated rendering engines, display control logic, and standard host CPU interfaces, allowing engineers to implement fluid user interfaces and detailed visual content without overloading the central host processor.
Core Advantages
Optimized 2D/3D Rendering Engine
The chip features a built-in hardware graphics accelerator capable of performing high-speed drawing functions such as line drawing, polygon mapping, bit-blending, and texture mapping. This localized processing significantly offloads the system CPU and delivers butter-smooth animations.
Flexible Multi-Layer Display Control
Supports multiple independent overlay display layers, enabling concurrent processing of backgrounds, UI overlays, maps, and real-time warnings. Hardware alpha-blending ensures transparency and professional transitions across layered visual components.
Automotive and Industrial Grade Reliability
Engineered to operate reliably under extreme environmental conditions, the MB86276PB-GS-ZE1 boasts robust thermal and electrical properties, making it compliant with strict automotive quality standards and rugged factory environments.
Versatile Host and Video Interfaces
Equipped with highly flexible interface configurations to hook up seamlessly with a broad array of 16/32-bit microcontrollers or embedded microprocessors, while directly driving digital LCD panels with minimal glue logic.
Key Specifications
| Brand | Fujitsu / SocioNext |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free |
| EDA/CAD Model | 3D Model & PCB Footprint Available upon request |
| Warranty | 1-Year Standard Factory Warranty |
| Package / Case | BGA-256 (Ball Grid Array) |
| Mounting Type | Surface Mount (SMD/SMT) |
| Surface Marking / Silkscreen | MB86276 Marking |
| Core Frequency | Up to 133 MHz |
| Memory Interface | Supports external SDRAM / FCRAM |
| Display Layers | Up to 4 fully configurable layers |
| Supply Voltage | 1.8V (Core), 3.3V (I/O) |
| Operating Temperature Range | -40°C to +85°C (Industrial/Automotive Grade) |
Typical Applications
- Automotive Digital Instrument Clusters and Dashboards
- In-Vehicle Infotainment (IVI) and Navigation Systems
- Industrial HMI (Human-Machine Interface) Panels
- Medical Imaging Monitors and Diagnostic Equipment Display Consoles
- Marine Navigation Indicators and Rugged Outdoor Displays
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is the MB86276PB-GS-ZE1 graphics controller an original factory part?
A: Yes, we guarantee that all MB86276PB-GS-ZE1 stock items are 100% genuine, factory-sealed, and sourced via reliable tracing networks.
Q2: What resolution parameters does this “Lime” processor typically handle?
A: It is ideal for typical embedded resolutions up to WVGA (800×480) or higher, depending on the refresh rate and structural layout configurations.
Q3: How fast will my order ship once payment goes through?
A: Orders are processed quickly and will be shipped within 1-2 business days for standard in-stock items.
Q4: Can I request documentation regarding package dimensional specifications and pinouts?
A: Certainly. Kindly submit a ticket via our Quick Inquiry form, and our engineer team will reply with the complete reference manual and datasheet within 24 hours.
