MLX90640ESF-BAA-000-TU
MLX90640ESF-BAA-000-TU
| Part Number | MLX90640ESF-BAA-000-TU |
| Manufacturer | Melexis |
| Category | Sensors > IR Thermal Sensors > 32×24 Pixel IR Array Thermal Imager |
| Description | 32×24 Pixels Infrared Array Thermal Sensor, Digital I2C Output, Wide Field of View BAA Version,TO-39 Package |
Product Overview
The MLX90640ESF-BAA-000-TU is a compact array-based infrared thermal imaging sensor developed by Melexis, integrating 768 individual IR detector pixels arranged in 32×24 matrix inside standard TO-39 housing. Equipped with internal signal conditioning and ADC circuits, the component outputs calibrated temperature data over standard I2C digital bus for straightforward MCU communication. BAA variant features wide field of view for large-area scene temperature scanning without mechanical movement, delivering reliable non-contact thermal mapping across broad temperature range. It is widely deployed for equipment heat inspection, human presence detection, industrial overheat monitoring and smart home thermal measurement systems.
Key Specifications
| Brand | Melexis |
| RoHS | RoHS Compliant |
| EDA / CAD | Symbols, Footprints, 3D Models Available |
| Warranty | 1 Year Standard Warranty |
| Package / Case | TO-39 |
| Mounting Type | Through Hole |
| Surface Marking / Silkscreen | MLX90640ESF-BAA-000-TU |
| Pixel Resolution | 32 × 24 (768 Pixels) |
| Field of View | BAA Wide Angle: 110° × 75° |
| Object Temperature Range | -40°C ~ 300°C |
| Operating Ambient Temp | -40°C ~ 85°C |
| Communication Interface | I2C |
| Supply Voltage | 3.3V |
Typical Applications
- Industrial Equipment Overheat Inspection & Thermal Scanning
- Smart Building Human Presence & Occupancy Detection
- HVAC Pipeline & Electrical Cabinet Temperature Monitoring
- Home Appliance Internal Thermal Fault Detection
- IoT Wireless Thermal Monitoring Sensor Nodes
- DIY Portable Miniature Thermal Imaging Devices
- Conveyor Production Line Non-contact Temperature Screening
- Greenhouse Environmental Thermal Distribution Monitoring
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Payment Methods: T/T (Bank Transfer), PayPal, Credit Card, Western Union
Technical Support
Frequently Asked Questions
Q1: Is MLX90640ESF-BAA-000-TU RoHS compliant?
A: Yes, this product fully complies with RoHS environmental standards.
Q2: Can I apply for product samples for testing?
A: Sample service is available, please submit your request via the Quick Inquiry form.
Q3: What is the package and mounting type?
A: It adopts TO-39 package and through hole mounting type for PCB assembly.
Q4: How long is the warranty period?
A: We provide 1 year standard warranty for all products.
