MLX90640ESF-BAB-000-TU
MLX90640ESF-BAB-000-TU
| Part Number | MLX90640ESF-BAB-000-TU |
| Manufacturer | Melexis |
| Category | Sensors > IR Thermal Sensors > 32×24 Pixel IR Array Thermal Imager |
| Description | 32×24 Pixels Infrared Array Thermal Sensor, Digital I2C Output, Narrow FOV BAB Version,TO-39-4 Package |
Product Overview
The MLX90640ESF-BAB-000-TU is a compact infrared array thermal imaging sensor manufactured by Melexis with a 32×24 pixel IR detector matrix encapsulated inside standard TO-39 housing. Integrated internal signal amplifier and high-precision ADC enable calibrated temperature data output via I2C digital interface for easy connection with MCU. The BAB version features narrow field of view for long-distance concentrated temperature detection, realizing non-contact regional thermal image acquisition without mechanical scanning components. With stable measurement performance and wide operating temperature range, it is widely used in precision equipment temperature inspection, remote target thermal monitoring, industrial pipeline temperature detection and intelligent IoT thermal measurement systems.
Key Specifications
| Brand | Melexis |
| RoHS | RoHS Compliant |
| EDA / CAD | Symbols, Footprints, 3D Models Available |
| Warranty | 1 Year Standard Warranty |
| Package / Case | TO-39-4 |
| Mounting Type | Through Hole |
| Surface Marking / Silkscreen | MLX90640ESF-BAB-000-TU |
| Pixel Resolution | 32 × 24 (768 Pixels) |
| Field of View | BAB Narrow Angle: 55° × 35° |
| Object Temperature Range | -40°C ~ 300°C |
| Operating Ambient Temp | -40°C ~ 85°C |
| Communication Interface | I2C |
| Supply Voltage | 3.3V |
Typical Applications
- Long-distance Electrical Equipment Hot Spot Inspection
- Industrial Furnace & Pipeline Local Temperature Monitoring
- Precision Equipment Component Thermal Fault Detection
- Smart Traffic Vehicle Localized Temperature Scanning
- IoT Remote Fixed-point Thermal Detection Nodes
- Laboratory Precision Non-contact Temperature Testing
- Automotive Engine Component Thermal Monitoring Modules
- Warehouse Fire Pre-warning Local Temperature Inspection
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Payment Methods: T/T (Bank Transfer), PayPal, Credit Card, Western Union
Technical Support
Frequently Asked Questions
Q1: Is MLX90640ESF-BAB-000-TU RoHS compliant?
A: Yes, this product fully complies with RoHS environmental standards.
Q2: Can I apply for product samples for testing?
A: Sample service is available, please submit your request via the Quick Inquiry form.
Q3: What is the package and mounting type?
A: It adopts TO-39-4 package and through hole mounting type for PCB assembly.
Q4: What is its pixel array specification?
A: It adopts 32×24 pixel matrix, total 768 IR detector pixels for thermal image capture.
