SN74LVC1G00DBVR
SN74LVC1G00DBVR
Basic Information
| Part Number | SN74LVC1G00DBVR |
| Manufacturer | Texas Instruments |
| Category | Integrated Circuits (ICs) > Logic > Gates > NAND Gates |
| Description | IC SINGLE 2-INPUT NAND GATE 5-SOT23, Single 2-Input Positive NAND Gate Logic IC |
Product Overview
The SN74LVC1G00DBVR is a single 2-input positive NAND gate optimized for low-voltage digital logic systems. It supports a wide supply voltage range, high-speed operation, and ultra-low power consumption while providing excellent noise immunity and signal integrity. The device is fully compatible with CMOS and TTL logic interfaces, making it suitable for general-purpose logic functions, signal gating, and control circuits in compact electronic designs. Housed in a tiny 5-SOT23 surface-mount package, it is ideal for portable electronics, IoT devices, wearable technology, and high-density embedded systems.
Key Specifications
| RoHS | RoHS Compliant |
| EDA/CAD Models | Available (Schematic, PCB Footprint, Symbol) |
| Warranty | 1 Year |
| Brand | Texas Instruments |
| Logic Type | Single 2-Input Positive NAND Gate |
| Voltage – Supply | 1.65V ~ 5.5V |
| Propagation Delay | Typical 3.8ns |
| Logic Compatibility | CMOS, TTL |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 5-SOT23-5 |
Typical Applications
- Portable Consumer Electronics
- Wearable Devices and Smart Sensors
- Digital Logic Control and Gating
- Microcontroller I/O Interface Circuits
- Low-Voltage Embedded Systems
- IoT Sensor Nodes and Modules
- High-Density PCB Digital Designs
- General-Purpose Logic Functions
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
