TB6608FNG
TB6608FNG
| Part Number | TB6608FNG |
|---|---|
| Manufacturer | Toshiba Electronic Devices & Storage Corporation |
| Category | Integrated Circuits (ICs) > Power Management > Motor Drivers |
| Description | DUAL DC MOTOR DRIVER, 2.0A CONTINUOUS, 2.5V TO 13.5V, -20 TO 85°C, HSSOP-24 |
Product Overview
The TB6608FNG is a dual-channel DC motor driver IC from Toshiba, designed for high-efficiency, low-voltage motor drive applications. This H-bridge driver supports two DC motors or one 2-phase stepper motor, delivering up to 2.0A continuous output current per channel with low on-resistance to minimize power dissipation. Operating over a wide voltage range of 2.5V to 13.5V, it features forward, reverse, brake, and standby control modes, along with built-in thermal shutdown, over-current protection, and under-voltage lockout for safe and reliable operation. Compatible with TTL/CMOS logic inputs, the TB6608FNG is ideal for compact robotics, consumer electronics, and mechatronic systems requiring stable and precise motor control in a small surface‑mount package.
Key Specifications
| Parameter | Value |
|---|---|
| RoHS | Compliant (RoHS 2/3 Compliant, Lead-Free) |
| EDA/CAD Models | Available (Gerber, STEP, IDF, Symbol, Footprint) |
| Warranty | 3 Years Standard Warranty |
| Brand | Toshiba |
| Motor Type | Dual DC Motors / Single 2-Phase Stepper Motor |
| Continuous Output Current | 2.0A per channel |
| Peak Output Current | 4.0A per channel |
| Supply Voltage | 2.5V to 13.5V |
| Logic Input | TTL / CMOS Compatible (2.0V–5.5V) |
| Operating Temperature | -20°C to +85°C |
| Package Type | HSSOP-24 (Heat Shrink Small Outline Package) |
| Protection Features | Thermal Shutdown, Over-Current, Under-Voltage Lockout |
| Control Modes | Forward, Reverse, Brake, Standby |
Typical Applications
- Small to Medium Robots and Robotic Platforms
- RC Cars, Drones, and Remote-Control Models
- Consumer Electronics (Printers, Cameras, Toys)
- DC and Stepper Motor Control Modules
- Portable Mechatronic Devices
- Smart Home Automation Actuators
- DIY Electronics and Maker Projects
- Educational Robotics Kits
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
