TC1-1T+
TC1-1T+
| Part Number | TC1-1T+ |
|---|---|
| Manufacturer | Mini-Circuits |
| Category | RF Transformers; Wideband RF Transformers |
| Description | 1:1 Wideband RF Transformer, 0.1-125 MHz, 50Ω Impedance, Surface Mount Package |
Product Overview
The TC1-1T+ is a high-performance 1:1 wideband surface-mount RF transformer designed for RF, IF, and low-frequency signal isolation, matching, and coupling applications. It operates over a wide frequency range from 0.1 MHz to 125 MHz with a standard 50Ω characteristic impedance, delivering excellent insertion loss, high return loss, and stable electrical performance across temperature and frequency variations. The device features compact form factor, rugged construction, and RoHS-compliant design, making it ideal for high-reliability communication, test equipment, and industrial RF systems. With consistent performance and wide operating bandwidth, it provides reliable signal conditioning for professional RF and analog circuits.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | Mini-Circuits |
| Turns Ratio | 1:1 |
| Frequency Range | 0.1 MHz – 125 MHz |
| Impedance | 50Ω |
| Operating Temperature | -40°C to +85°C |
Typical Applications
- RF and IF Signal Coupling & Isolation
- Impedance Matching Networks
- Balun & Differential Signal Conversion
- Communication Transceivers & Radio Systems
- Test & Measurement Instrumentation
- Industrial RF & Analog Circuits
- Broadband Signal Conditioning
- Low-Frequency RF Transceiver Modules
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
