TCD1254GFG
TCD1254GFG
| Part Number | TCD1254GFG |
|---|---|
| Manufacturer | Hamamatsu Photonics |
| Category | Image Sensors; CCD Linear Image Sensor |
| Description | 2500-Pixel CCD Linear Image Sensor, High Sensitivity, Low Dark Current, QFN-16(6×19) Package |
Product Overview
The TCD1254GFG is a high-performance 2500-pixel CCD linear image sensor designed for high-precision optical scanning and measurement applications. It features high photosensitivity, low dark current, excellent linearity, and stable output characteristics for accurate light intensity detection and image acquisition. The device offers wide spectral response, high dynamic range, and reliable operation for industrial and professional optical systems. Housed in a compact surface-mount package, it supports compact optical equipment design and high-precision scanning applications.
| Key Specifications | |
|---|---|
| Brand | Hamamatsu Photonics |
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Package / Case | QFN-16(6×19) Package |
| Mounting Type | Surface Mount (SMD) |
| Surface Marking / Silkscreen | TCD1254 |
| Number of Pixels | 2500 Pixels |
| Pixel Size | 5.25umx64um |
| Spectral Response Range | 300 nm ~ 1000 nm |
| Operating Temperature | -25°C to +60°C |
Typical Applications
- Image Scanners & Document Scanning Systems
- Optical Measurement & Inspection Equipment
- Industrial Machine Vision Systems
- Barcode & Mark Reading Devices
- Spectrometry & Optical Analysis Instruments
- Position & Dimension Measurement Systems
- Photoelectric Detection & Sensing Modules
- High-Precision Optical Imaging Equipment
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
