TMC5160A-TA-T
TMC5160A-TA-T
| Part Number | TMC5160A-TA-T |
| Manufacturer | TRINAMIC |
| Category | Motor Driver IC / Stepper Motor Driver Chip |
| Description | High-Power Bipolar Stepper Motor Controller & Driver with Serial Communication Interfaces,TQFP-48-EP(7×7) Package |
Product Overview
The TMC5160A-TA-T is a high-performance bipolar stepper motor controller and driver IC from TRINAMIC, featuring advanced motion control technology for ultra-silent, high-torque operation. It integrates a flexible ramp generator and industry-leading chopper schemes like StealthChop2™ and SpreadCycle™, delivering smooth motion, low noise, and precise positioning for demanding applications.
Core Advantages
1. Ultra-silent motor operation with StealthChop2™ technology, eliminating noise and resonance even at high speeds.
2. High torque output with excellent current accuracy and up to 256 microstep resolution for superior positioning precision.
3. Integrated motion controller offloads complex trajectory calculations, reducing MCU resource usage and simplifying system design.
4. Built-in protection mechanisms including over temperature, over current, and short circuit protection to maximize equipment safety.
5. Flexible control interfaces (SPI / UART / Step/Dir) and support for advanced features like StallGuard2™ and CoolStep™.
Key Specifications
| Brand | TRINAMIC |
| RoHS | Compliant |
| EDA/CAD Models | Symbols, Footprints, 3D Models Available |
| Warranty | 1 Year Standard Warranty |
| Package / Case | TQFP-48-EP (7x7mm) |
| Mounting Type | Surface Mount |
| Surface Marking / Silkscreen | TMC5160A-TA Marking |
| Motor Type | Bipolar Stepper Motor |
| Control Voltage | 3.3V ~ 5V |
| Motor Supply Voltage | 8V ~ 60V |
| Output Current | Up to 13.6A Peak (8A RMS) |
| Step Resolution | Up to 256 Microsteps |
| Operating Temperature | -40°C ~ +125°C |
| Key Features | StealthChop2™, SpreadCycle™, StallGuard2™, CoolStep™, SPI/UART/Step-Dir Interfaces |
Typical Applications
- Industrial Automation Equipment
- Robotics and Servo Systems
- CNC Machinery and 3D Printers
- Medical Motion Control Devices
- Automation Conveying Equipment
- Precision Positioning Systems
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Payment Methods: T/T (Bank Transfer), PayPal, Credit Card, Western Union
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is this component RoHS compliant?
A: Yes, TMC5160A-TA-T fully meets RoHS environmental standards.
Q2: What is the mounting method of this chip?
A: It adopts surface mount type with TQFP-48-EP (7x7mm) package for automated assembly.
Q3: Can it be used for 3D printer stepper motor drive?
A: Absolutely, it is an ideal choice for high-performance 3D printer motion control with ultra-quiet operation.
Q4: What is the maximum motor voltage supported?
A: It supports a wide motor supply voltage range of 8V to 60V, suitable for various high-power stepper motors.
Q5: Do you provide technical documents and samples?
A: We can offer complete datasheets and support sample application via inquiry form.
