AS5145B-HSSM
AS5145B-HSSM
| Part Number | AS5145B-HSSM |
|---|---|
| Manufacturer | ams OSRAM |
| Category | Position Sensors; Magnetic Rotary Encoder |
| Description | 12-Bit High-Speed Magnetic Rotary Position Sensor, SPI & PWM Outputs, SSOP-16 Package |
Product Overview
The AS5145B-HSSM is a high-speed, non-contact magnetic rotary encoder designed for accurate 360° absolute angle measurement in industrial and automotive applications. It features contactless sensing technology for reliable operation in harsh environments with dust, vibration, and moisture. The device offers 12-bit high resolution, dual SPI and PWM output interfaces, low power consumption, and built-in error detection and diagnostics. It supports wide voltage and temperature ranges for robust performance. Housed in a compact SSOP-16-208mil surface-mount package, it is ideal for high-speed motion control, position feedback, and precision actuator systems.
| Key Specifications | |
|---|---|
| Brand | ams OSRAM |
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Package / Case | SSOP-16-208mil |
| Mounting Type | Surface Mount (SMD) |
| Resolution | 12-Bit (0.087°) |
| Measurement Range | 0° ~ 360° Full Rotation |
| Output Interface | SPI + PWM Digital Outputs |
| Supply Voltage | 3.0V ~ 5.5V |
| Operating Temperature | -40°C to +125°C |
Typical Applications
- High-Speed Servo Motors & Drives
- Industrial Robotics & Automation
- Automotive Actuators & Position Control
- Pan-Tilt Systems & Camera Platforms
- Precision Medical Equipment
- Angle Feedback & Motion Control Systems
- HVAC Valves & Damper Controls
- High-Performance Industrial Sensors
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
