IRFD120PBF
IRFD120PBF
| Part Number | IRFD120PBF |
|---|---|
| Manufacturer | VISHAY |
| Category | MOSFETs; N-Channel High Voltage Power MOSFET |
| Description | N-channel enhancement type high voltage MOSFET, low gate charge,100V,1.3A,270mΩ,HVMDIP-4 through-hole package |
Product Overview
The IRFD120PBF is a high voltage N-channel power MOSFET manufactured by VISHAY. It features low input gate charge, stable high voltage blocking capability and reliable switching performance for low to medium current high voltage circuits. With compact HVMDIP-4 package design, the device saves PCB layout space and simplifies assembly processing. It is widely used in small switching power supplies, charger control circuits, high voltage LED drivers and household appliance power control modules.
| Key Specifications | |
|---|---|
| Brand | VISHAY |
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Package / Case | HVMDIP-4 |
| Mounting Type | Through Hole |
| Surface Marking / Silkscreen | IRFD120 Marking |
| Channel Type | N-Channel |
| Drain-Source Voltage (Vds) | 100 V |
| Continuous Drain Current (Id) | 1.3 A |
| Operating Temperature | -55°C to +150°C |
Typical Applications
- Small Offline Switching Power Supplies
- Battery Charger High Side Switching
- High Voltage LED Driver Control Circuits
- Home Appliance Auxiliary Power Control
- Low Power AC-DC Adapter Design
- Small Size High Voltage Pulse Circuits
- General High Voltage Low Current Switching
- IoT Equipment Isolated Power Modules
