P1010NSE5DFB
P1010NSE5DFB
| Part Number | P1010NSE5DFB |
|---|---|
| Manufacturer | NXP Semiconductors (Freescale) |
| Category | Integrated Circuits (ICs) > Embedded – Microprocessors / QorIQ P1 Series Processors |
| Description | High-efficiency NXP QorIQ P1010 single-core processor (533MHz e500v2), integrated DDR3/DDR3L controller, 3 Gigabit Ethernet, PCIe 2.0, USB 2.0 & hardware crypto engine, 425-pin lead-free MAPBGA for industrial gateway & smart grid devices. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
P1010NSE5DFB is a low-power 45nm QorIQ P1 series SoC from NXP, designed for networking, industrial control and smart grid equipment. Equipped with a single 533MHz e500v2 core, 32KB L1 instruction/32KB L1 data cache and 256KB shared L2 cache, it integrates DDR3/DDR3L controller, 3-channel Gigabit Ethernet, PCIe 2.0, USB2.0, SATA and SEC4.4 encryption engine. Packaged in 425-pin lead-free MAPBGA, it delivers stable performance for secure edge routing devices.
Core Advantages
Power-Efficient e500v2 Core
533MHz 32-bit dual-issue processor with outstanding power efficiency, supporting stable fanless equipment operation.
Multi-Port Gigabit Ethernet Integration
3 built-in gigabit MACs with packet parsing offload, reducing main core load and boosting data throughput.
Built-In Hardware Encryption Engine
SEC4.4 crypto accelerator supports IPsec/SSL/TLS without occupying main processor resources.
Rich Industrial Peripheral Interfaces
Integrated PCIe 2.0, SATA and DDR3/DDR3L memory interface, lowering PCB peripheral layout complexity.
Key Specifications
| Brand | NXP Semiconductors QorIQ® P1 Series Microprocessors |
|---|---|
| Manufacturer Part Number | P1010NSE5DFB |
| RoHS Status | RoHS Compliant / Lead-Free / Green Manufacturing Standards Verified |
| EDA/CAD Model | 3D STEP Models, Schematic Symbols, and Pinout Footprint Configurations available upon request |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | 425-LFBGA / MAPBGA (19mm × 19mm × 0.80mm) |
| Mounting Type | Surface Mount |
| Surface Marking / Silkscreen | P1010NSE5DFB Marking |
| Processor Core | Single e500v2 Power Architecture® 32-Bit Microprocessor |
| Max Core Clock Frequency | 533 MHz |
| L1 Instruction Cache | 32 KB |
| L1 Data Cache | 32 KB |
| Integrated L2 Cache / SRAM Block | 256 KB unified memory structure with ECC capability |
| Memory Interface Support | 32-bit DDR3 / DDR3L SDRAM up to 800 MT/s data rates with ECC option |
| Ethernet Interfaces | 3× 10/100/1000 Mbps MACs supporting RGMII, MII, SGMII protocols |
| PCI Express Subsystem | 1× PCI Express Gen 2.0 link, up to 5 Gbps line speed |
| Additional High-Speed I/O | 2× SATA 2.0 links, 2× USB 2.0 controllers with integrated PHYs, 2× CAN 2.0B interfaces |
| Hardware Security Engine | SEC 4.4 Cryptographic Accelerator (IPsec, SSL/TLS Encryption Support) |
| Core Operating Supply Rail | 1.0 V core voltage; flexible 1.5V/1.8V/2.5V/3.3V I/O voltage options |
| Operating Temperature Range | 0°C to +105°C Junction Temperature (T_J), industrial extended temperature grade |
| Storage Temperature Range | -40°C ~ +125°C |
| Data Bus Width | 32 Bit |
| Lead Status | Lead Free |
Typical Applications
- Enterprise Edge Routers, Multi-Service Integrated Gateways, and Network Attached Storage (NAS)
- Industrial Automation Controllers, Programmable Automation Controllers (PACs), and Human Machine Interfaces
- Smart Grid Communication Units, Power Line Aggregators, and Distributed Energy Resource Monitors
- Multiservice Wireless Access Points, Secure Field Firewalls, and Integrated Threat Management Boxes
- Embedded Printing Subsystems, Advanced Media Controllers, and Medical Device Telemetry Hubs
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
Submit requests for datasheets, samples, stock checks or bulk quotes via our inquiry form. All messages will be replied within 24 hours.
Frequently Asked Questions
Q1: Are your P1010NSE5DFB chips 100% original?
A1: All stock is brand-new NXP factory original. Every batch passes ESD inspection and traceability check, stored in original JEDEC trays.
Q2: What do NS and E stand for in the part number?
A2: NS = standard 0~105°C industrial temperature grade; E = built-in SEC4.4 hardware encryption engine.
Q3: Does P1010NSE5DFB support DDR3L low-voltage memory?
A3: Yes, the memory controller supports both 1.5V DDR3 and 1.35V DDR3L to lower system power consumption.
Q4: How to get datasheets and bulk pricing?
A4: Fill out the inquiry form on this page, we will send complete docs and customized quotes within 24h.
Q5: What is the minimum order quantity?
A5: MOQ is 1 piece, small sample orders are supported for project testing.
Q6: How long is the warranty period?
A6: We provide a 1-year quality warranty for all purchased chips.
Q7: How fast will items be shipped after payment?
A7: In-stock parts will be shipped within 1-2 working days after order confirmation.
Q8: Can I get free samples for my project verification?
A8: Free sample service is available for large-volume follow-up orders, contact us to apply.
Q9: What shipping methods do you support?
A9: We offer DHL, FedEx, UPS and EMS for global delivery.
